3-in-1 Mini Excavator Attachment Set – 25mm Pins

Mini Excavator Attachments Set (25mm Pins) – Rake, Ripper & Quick Hitch

Built for 0.5–1.5t mini excavators with a 25mm pin diameter (85mm pin centres, 90mm dipper gap), these attachments combine reinforced steel construction with precise engineering to ensure durability, reliability, and efficiency in demanding conditions. Compatible with popular models such as Rhinoceros XN08, XN10-8, and XN12-9, they are essential tools for operators across construction, landscaping, utilities, and agriculture.

Excavator Rake (500mm × 450mm)
Heavy-duty rake designed to clear brush, rocks, roots, and job-site debris in a single pass. Built from reinforced steel for maximum strength, it digs through tough material without flexing, making it ideal for site cleanup and land preparation.

Specifications:
Width × Length: 500mm × 450mm
Pin Diameter: 25mm
Pin Centres: 85mm
Dipper Gap (Ear Width): 90mm

Ripper Tooth (320mm Tooth Length)
Engineered for tough ground conditions, the ripper tooth delivers deep penetration into compacted soil, clay, roots, frozen ground, and fractured rock. Its single-hook design allows powerful ripping even in confined spaces.

Specifications:
Tooth Length: 320mm
Pin Diameter: 25mm
Pin Centres: 85mm
Dipper Gap (Ear Width): 90mm

Mechanical Quick Hitch (25mm Pin, Mark 2)
A reliable manual quick coupler that simplifies attachment changes by eliminating the need to remove shafts and sleeves. Built from high-strength steel alloy with grease nipple pins, it ensures wear resistance and long service life. The simple screw-locking system allows fast, secure changes even for less experienced operators.

Specifications:
Pin Diameter: 25mm
Pin Centres: 85mm
Dipper Gap (Ear Width): 90mm
Design: Manual (Mark 2) with Grease Nipple Pins
